Model:Ablept RUV/SUV/S1020UV light solidification high resolution inkjet printer

Applicable scope:flexible packaging, plastic, metal and carton, etc.

Printing content:date, Chinese characters, graphics, bar code, QR code and numbers, etc.

Operation software:touch screen

1.Reduce costs

2.Improve quality

3.Environmental protection

4.UV ink is solvent-free and environmental protection material.

1.A standard host can drive four 7-point, two 16-point and one 32-point nozzles simultaneously. Additional nozzles need to be customized.

2.Storage information: 1G storage capacity for print information (memory can be extended by communicating with the print-out line host PC)

3.Coding font: The printing of English letters, numeric codes, Chinese, etc. can be accommodated.

4.Coding font size: from 5 to128mm, with font width is adjustable.

5.Character width: the distance between different characters can be set at the operator interface, making it easier for the technical department to set the standard.

6.Inkjet drying time: 3-5 meters (depending on line speed in production line)

7.Character format: bold, reverse, inverted and inverted embossed characters

8.Information properties: global settings, dot size, character width, dot spacing, and print margins

9.Coding information: Chinese and English characters, numbers, date and times, counters, shifts, and graphics, etc.

10.Trigger methods: non-trigger, external photoelectric switch, encoder, etc.

11.Editing methods: sensitive trigger operation, supports for multi-point input, sensitive editing/movement of text messages according to the use.

12.Distance between the two coded messages: Distance between two coded messages: Adjustable according to production requirements, also depending on the trigger method.

13.Communication interface: the host computer can be connected to the host PC via RS232(the host PC is purchased by the customer), and can automatically print codes according to the specifications selected by the host PC.

14.Operation traceability: the system work log can be queried for easy traceability.

1、More convenient operation and more accurate positioning;

2、The machine stops without leaking ink, making the site cleaner and more attractive.

3、The stitch marker can be configured according to customer requirements for the width of the identification lines.

4、The width of the color line is uniform and beautiful.

Nozzle size:62 pm

The maximum printline is three

Character height:1.8 to 20 mm

Single line printing6.25 m/s

Maximum speed(0.47mm point distance）

Dual-line print2.46 m/s

Maximum speed0.43 mm pitch

The recommended distance between printhead12mm (35mm
